SKU · OCTA-SELL 1재고 있음

OCTA-SELL | Self-Generating Disinfectant Endoscope Disinfector FOUR-O LAB's OCTA-SELL is designed for the disinfection of flexible endoscopes, including gastroscopes and colonoscopes. The device first rinses the endoscope using purified or tap water, then activates an internal electrolysis unit to generate hypochlorite(OCl-) directly on-site, supplying the freshly produced disinfectant to the soaking chamber. This process delivers high-level disinfection in compliance with Korean Ministry of Health and Welfare guidelines, producing electrochemically activated free chlorine at concentrations of 650–675 ppm or above at the point of use. Beyond flexible endoscopes, OCTA-SELL is also suitable for disinfecting gynecological specula, ENT laryngoscopes, and endoscope-related accessories, excluding any items that require full sterilization. Difference between OCTA-SELL 1 & 2 The standard OCTA-SELL has a single-chamber and features ultrasonic cleaning, an integrated leak test, and an air flush function. It requires purified salt replenishment every 20 cycles - sufficient to disinfect up to 20 endoscopes. The OCTA-SELL 2 has dual-chember and retains all of these capabilities while adding a built-in alcohol drying system that makes a faster drying possible. Salt replenishment is required every 25 cycles, supporting up to 50 endoscopes per load. < The MOQ is 10 units. To order a smaller quantity, please contact fourolab@gmail.com >

최소 주문 수량10
리드타임예: 3-4 weeks
원산지South Korea
포장Standard export packaging
카트에 담은 제품을 한 번에 견적 요청할 수 있습니다.
제품 설명

OCTA-SELL | Self-Generating Disinfectant Endoscope Disinfector FOUR-O LAB's OCTA-SELL is designed for the disinfection of flexible endoscopes, including gastroscopes and colonoscopes. The device first rinses the endoscope using purified or tap water, then activates an internal electrolysis unit to generate hypochlorite(OCl-) directly on-site, supplying the freshly produced disinfectant to the soaking chamber. This process delivers high-level disinfection in compliance with Korean Ministry of Health and Welfare guidelines, producing electrochemically activated free chlorine at concentrations of 650–675 ppm or above at the point of use. Beyond flexible endoscopes, OCTA-SELL is also suitable for disinfecting gynecological specula, ENT laryngoscopes, and endoscope-related accessories, excluding any items that require full sterilization. Difference between OCTA-SELL 1 & 2 The standard OCTA-SELL has a single-chamber and features ultrasonic cleaning, an integrated leak test, and an air flush function. It requires purified salt replenishment every 20 cycles - sufficient to disinfect up to 20 endoscopes. The OCTA-SELL 2 has dual-chember and retains all of these capabilities while adding a built-in alcohol drying system that makes a faster drying possible. Salt replenishment is required every 25 cycles, supporting up to 50 endoscopes per load. < The MOQ is 10 units. To order a smaller quantity, please contact fourolab@gmail.com >

사양

사양 12항목

Weight80 kg
Dimensions560mm (W) × 630mm (D) × 920mm (H)
Chamber Capacity10L ± 5%
Tank CapacitySalt 28L / Disinfectant 3L
Max EndoscopesUp to 20
Salt ReplenishmentEvery 20 cycles
Cleaning MethodImmersion + Ultrasonic
Drainage MethodAutomatic (single use)
DryingAir Dry
Operation TimeManual/Auto: 8 min 30 sec(Pre-cleaning->Ultrasonic Disinfection->Ultrasonic Cleaning->Post-cleaning->Drying))
Disinfectant Conc.≥ 650-675 ppm
Electrical SpecificationsAC 220V, 60Hz, 550VA
인증 · 기록

보유 인증 11건

인증GMP Certificate (Korean Ministry of Food and Drug Safety)Medical Device Manufacturing License (Korean MFDS)OCTA-SELL Product License (Korean MFDS)Patent No. 10-2297143 (Korea)ISO 13485Philippines CFSRussia CFSVietnam CFSCE(LVD, RoHS, EMC)ISO 9001ISO 14001
